Operators ¶

Every Business Process requires an Operator. This operator defines its behaviour and specifies how its very own state is going to be calculated.

AND ¶

The AND operator selects the WORST state of its child nodes:

And Operator

OR ¶

The OR operator selects the BEST state of its child nodes:

Or Operator

Or Operator #2

DEGRADED ¶

The DEGRADED operator behaves like an AND, but if the resulting state is CRITICAL it transforms it into a WARNING. Refer to the table below for the case-by-case analysis of the statuses.

Degraded Operator

MIN n ¶

The MIN operator selects the WORST state out of the BEST n child node states:

MIN
